The sketch project contains the following pdf files with measurements:
foundation, floor and roof plan
explanatory note with general data
general square meters of structural surfaces for calculating approximate amount of material needed for for the construction of a building
plan for luminaries, switches and connectors
- Raft foundation
- Lightweight block walls
- Roof on wooden structures
- Partitions on a metal frame with plasterboard
Professional file formats (dwg and pln) can also be purchased.
The sketch project is completed within 1 week of ordering.
